安全认证：
|
|
|
XX
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
无防爆要求
|
|
|
XM
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
船用许可
|
|
|
CX
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
ATEX II 1G, 1/2G, 2G Ex ia IIC T6...T1 Ga, Ga/Gb, Gb
|
|
|
CA
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
ATEX II 1G, 1/2G, 2G Ex ia IIC T6 + WHG
|
|
|
CM
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
ATEX II 1G, 1/2G, 2G Ex ia IIC T6 + 船用许可
|
|
|
CK
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
ATEX II 1G,1/2G,2G Ex ia IIC T6+1/2D,2D Ex tD IP66 T
|
|
|
CI
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
IECEx Ex ia IIC T6 Ga, Ga/Gb, Gb
|
|
|
DX
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
ATEX II 1/2G, 2G Ex d ia IIC T6
|
|
|
DI
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
IECEx Ex d ia IIC T6
|
|
|
GX
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
ATEX II 1/2D, 2D Ex tD IP66 T
|
|
|
GI
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
IECEx Ex tD A20/21,A21 IP66 T
|
|
|
│
|
|
|
|
|
|
|
|
|
版本/工作温度：
|
|
|
│
|
E
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
PE 绝缘 / -40～80°C
|
|
|
│
|
F
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
PTFE 绝缘 / -50～150°C
|
|
|
│
|
G
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
PTFE 绝缘 / -50～200°C
|
|
|
│
|
H
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
PE绝缘及316L同轴管 / -40～80°C
|
|
|
│
|
I
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
PTFE绝缘及316L同轴管 / -50～150°C
|
|
|
│
|
J
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
PTFE绝缘及316L同轴管 / -50～200°C
|
|
|
│
|
│
|
|
|
|
|
|
|
|
安装连接/材料：
|
|
|
│
|
│
|
GA
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
螺纹 G3/4(DIN3852-A)PN64 / 316L
|
|
|
│
|
│
|
NA
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
螺纹 3/4NPT(ASME B1.20.1) PN64 / 316L
|
|
|
│
|
│
|
NI
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
螺纹 3/4NPT(ASME B1.20.1) PN64 / Hastelloy C22 2.4602
|
|
|
│
|
│
|
GC
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
螺纹 G1 (DIN3852-A) PN64 / 316L
|
|
|
│
|
│
|
NC
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
螺纹 1NPT(ASME B1.20.1) PN64 / 316L
|
|
|
│
|
│
|
GD
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
螺纹 G1 1/2(DIN3852-A) PN64 / 316L
|
|
|
│
|
│
|
GS
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
螺纹 G1 1/2(DIN3852-A) PN64 /Stahl
|
|
|
│
|
│
|
ND
|
┄
|
|
┄
|
┄
|
┄
|
┄
|
螺纹 1 1/2NPT(ASME B1.20.1) PN64 / 316L
|
|
|
│
|
│
|
EF
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
法兰 DN50PN40 Form C, DIN2501 / 316L
|
|
|
│
|
│
|
KF
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
法兰 DN80PN40 Form C, DIN2501 / 316L
|
|
|
│
|
│
|
MF
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
法兰 DN100PN16 Form C, DIN2501 / 316L
|
|
|
│
|
│
|
HA
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
法兰 2" 150lb RF, ANSI B16.5 / 316L
|
|
|
│
|
│
|
OA
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
法兰 3" 150lb RF, ANSI B16.5 / 316L
|
|
|
│
|
│
|
SA
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
法兰 4" 150lb RF, ANSI B16.5 / 316L
|
|
|
│
|
│
|
CV
|
┄
|
┄
|
┄
|
┄
|
┄
|
┄
|
法兰 DN100 16K RF,JIS / 316L
|
|
|
│
|
│
|
│
|
|
|
|
|
|
|
输出接口：
|
|
|
│
|
│
|
│
|
H
|
┄
|
┄
|
┄
|
┄
|
┄
|
4～20mA/HART
|
|
|
│
|
│
|
│
|
X
|
┄
|
┄
|
┄
|
┄
|
┄
|
连接到专用信号处理仪表
|
|
|
│
|
│
|
│
|
P
|
┄
|
┄
|
┄
|
┄
|
┄
|
Profibus PA
|
|
|
│
|
│
|
│
|
F
|
┄
|
┄
|
┄
|
┄
|
┄
|
Foundation Fieldbus
|
|
|
│
|
│
|
│
|
│
|
|
|
|
|
|
外壳/防护等级：
|
|
|
│
|
│
|
│
|
│
|
K
|
┄
|
┄
|
┄
|
┄
|
塑料外壳 / IP66/IP67
|
|
|
│
|
│
|
│
|
│
|
A
|
┄
|
┄
|
┄
|
┄
|
铝外壳 / IP66/IP68 (0.2 bar)
|
|
|
│
|
│
|
│
|
│
|
D
|
┄
|
┄
|
┄
|
┄
|
铝壳双室 / IP66/IP68 (0.2 bar)
|
|
|
│
|
│
|
│
|
│
|
8
|
┄
|
┄
|
┄
|
┄
|
不锈钢(电解抛光) 316L / IP66/IP68 (0.2 bar)
|
|
|
│
|
│
|
│
|
│
|
W
|
┄
|
┄
|
┄
|
┄
|
不锈钢双室 / IP66/IP68 (0.2 bar)
|
|
|
│
|
│
|
│
|
│
|
R
|
┄
|
┄
|
┄
|
┄
|
塑料双室 / IP66/IP67
|
|
|
│
|
│
|
│
|
│
|
│
|
|
|
|
|
连接电缆/电缆密封盖/连接插头：
|
|
|
│
|
│
|
│
|
│
|
│
|
M
|
┄
|
┄
|
┄
|
M20x1.5 /有/无
|
|
|
│
|
│
|
│
|
│
|
│
|
N
|
┄
|
┄
|
┄
|
1/2NPT /无/无
|
|
|
│
|
│
|
│
|
│
|
│
|
│
|
|
|
|
显示调试模块(PLICSCOM)：
|
|
|
│
|
│
|
│
|
│
|
│
|
│
|
X
|
┄
|
┄
|
无
|
|
|
│
|
│
|
│
|
│
|
│
|
│
|
A
|
┄
|
┄
|
顶部安装
|
|
|
│
|
│
|
│
|
│
|
│
|
│
|
│
|
|
|
附加设备：
|
|
|
│
|
│
|
│
|
│
|
│
|
│
|
│
|
X
|
┄
|
无
|
|
|
↓
|
↓
|
↓
|
↓
|
↓
|
↓
|
↓
|
↓
|
|
|
|
CL63.
|
##
|
#
|
##
|
#
|
#
|
#
|
#
|
#
|
|
：选定型号
|
